发布时间：2013-08-28 16:54:00 浏览次数：
规格下载： 点击下载
|
型号 |
电压 |
电阻 |
频率 |
入转矩 |
自定位转矩 （mN.m) |
空载牵入频率 (PPS) |
空载牵出频率 (PPS) |
步距角 (1-2相） |
|
||||||||
| 24BYJ48 | 5 | 60 | 100 | ≥29.4 | ≥29.4 | ≥500 | ≥900 | 5.625°/64 |
|
|
||||||||
| 24BYJ48 | 12 | 70 | 100 | ≥78.4 | ≥29.4 | ≥500 | ≥900 | 5.625°/64 |
| 24BYJ48 | 12 | 25 | 100 | ≥294 | ≥29.4 | ≥500 | ≥900 | 5.625°/64 |
|
|
||||||||
| 24BYJ48 | 12 | 200 | 100 | ≥58.8 | ≥29.4 | ≥500 | ≥900 | 5.625°/64 |
|
|
||||||||
| 24BYJ48 | 12 | 300 | 100 | ≥58.8 | ≥29.4 | ≥500 | ≥900 | 5.625°/64 |
|
|
||||||||
| 24BYJ48 | 12 | 300 | 100 | ≥9.80 | ≥7.35 | ≥300 | ≥600 | 5.625°/16 |
|
|
||||||||
| 24BYJ48 | 24 | 200 | 100 | ≥58.8 | ≥19.6 | ≥400 | ≥500 | 11.25°/64 |
|
|
||||||||
